Core

NiZn/Iron /MnZn/Magnetic metal powder

Inductance Range

13mH Min

Working Frequency Range

20KHZ-1MHz

Resistance to Soldering Heat

+260 °C, 40 sec. max.

Operating Temperature

--20℃~+105℃

Storage Temperature

-25℃~+85℃

Storage Humidity

30% to 95%

Test Items

* Turns Ratio

* Inductance

* DC resistance test

* Safety test

*Current test

* Hi-POT

Certification

ISO9001, CE, UL, ROHS,

Features

Low temperature rise

Small size with high efficiency

Stable performance

Applications

1. switching power supply

2. electrical home appliance

3. medical equipments

4. communication device

5. solar energy and inverter

6. car charging pile and car charger

7. security products and smart home
